Freightliner VO355 Aerial Bucket Truck

Product Description

1) KENWORTH M2106 4×4 CHASSIS
-3000RDS TRANSMISSION
-577 MILES
-300HP DD8

1) VERSALIFT VO-355X-MHI INSULATED 55′ 3″ OVER-CENTER, ARTICULATED AERIAL
PLATFORM LIFT WITH A 60′ 3″ WORKING HEIGHT, INCLUDING:
-STANDARD PLATFORM CAPACITY 700 LBS.
-UPPER BOOM ARTICULATION IS 210 DEGREES RELATIVE TO LOWER BOOM.
-LOWER BOOM ARTICULATION IS 125 DEGREES, FROM HORIZONTAL TO 35 DEGREES PAST VERTICAL.
-TRUGUARD DIELECTRIC ISOLATING SYSTEM WITH UNITROL LEFT HAND SINGLE STICK
CONTROL. ALL CONTROL HANDLES ARE ISOLATED AND TESTED PER ANSI 92.2. THE HIGH
RESISTIVE DIELECTRIC SYSTEM IS PROTECTED FROM DIRECT ENVIRONMENTAL AND JOB
RELATED CONTAMINATION. TRUGUARD TECHNOLOGY INCORPORATES THE USE OF FULL
HYDRAULIC CONTROLS WITH DURABLE METAL HANDLES AND LINKAGES.
-AUTOMATIC THROTTLE CONTROL ACTIVATES WITH TRIGGER AT SINGLE STICK
-FULL PRESSURE TURRET MOUNTED CONTROLS WITH OVERRIDE.
-ENGINE START/STOP FROM PLATFORM AND LOWER CONTROLS.
-OPEN CENTER HYDRAULIC SYSTEM PROVIDING FROM 8 GPM (30 LPM) TO 12 GPM (45 LPM)
AND 3000 PSI (210 KG/CM²) SYSTEM PRESSURE.
-MATERIAL HANDELING AND JIB PREP PACKAGE
-HYDRAULIC 90° PLATFORM ROTATION WITH HYDRAULIC TILT FOR CLEANOUT OR RESCUE.
-FIBERGLASS UPPER BOOM WITH TEST BAND TESTED PER ANSI A92.2 FOR CATEGORY B69-KV.
-VACUUM FLASHOVER PREVENTION SYSTEM.
-CHASSIS INSULATING SYSTEM (LOWER BOOM INSERT) PROVIDING 24 INSULATION GAP
INCLUDING ACCOMMODATIONS TO BRIDGE INSULATION GAP FOR TESTING PER ANSI A92.2
-WHITE URETHANE OVER WHITE GEL COAT ON FIBERGLASS UPPER BOOM AND LOWER BOOM INSERT.
-TWO (2) SETS OF HYDRAULIC TOOL OUTLETS AT PLATFORM WITH 2000 PSI REDUCING VALVE
-TWO (2) DIAMETER RETURN LINES.
-EXTERNAL RESERVOIR WITH A 30 GALLON (110 L) CAPACITY AND SIGHT LEVEL GAUGE.
-DUAL X-FRAME OUTRIGGERS WITH OUTRIGGER BOOM INTERLOCK SYSTEM
-AUTOMATIC BOOM REST.
-FULL LENGTH SUB FRAME AND MOUNTING HARDWARE FOR CAB AND CHASSIS.
-PAINTED WHITE TO MATCH FREIGHTLINER CAB CHASSIS. PAINT CODE L0006EY
-TWO SAFETY HARNESSES AND LANYARDS
-TWO (2) OPERATORS AND TWO (2) SERVICE MANUALS.
-MANUFACTURED AND TESTED PER ANSI A92.2
-CONTINUOUS ROTATION WITH ENGINE START/STOP AND 12 VOLT BACKUP PUMP.
-ONE (1) TWO-MAN 24 X 48 X 42 DEEP CLOSED FIBERGLASS BASKET WITH STEP
-PLATFORM COVER AND LINER.

1) DAKOTA BODIES 156 IN. X 54 IN. X 94 IN. STEEL LINE BODY

INCLUDING THE FOLLOWING:
-GREY ZOLATONE PAINT IN INTERIOR OF COMPARTMENTS
-STAINLESS STEEL AUTOMOTIVE ROTARY TYPE DOOR LATCHES AND HINGES.
-SPRING LOADED DOOR HOLDERS ON VERTICAL DOORS AND CHAIN STOPS ON HORIZONTALS.
-RUBBER ROLLED CROWN TYPE FENDERS AND AUTOMOTIVE BULB TYPE WEATHER STRIPPING.
MASTER DOOR LOCK SYSTEM.
-STANDARD ROPE LIGHT (3/8 LED 1 ON CENTER) COMPARTMENT LIGHTS IN ALL BODY
COMPARTMENTS.
-TWO (2) UNDER BODY MOUNTED 25 X 25 X 5 OUTRIGGER PAD HOLDERS
STREET SIDE COMPARTMENTS:
-1ST VERTICAL: 24 IN. – FIVE (5) FIXED MATERIAL HOOKS (1-3-1).
-2ND VERTICAL: 24 IN. – TWO (2) ADJUSTABLE SHELVES WITH DIVIDERS
-3RD VERTICAL: 24 IN. – TWO (2) ADJUSTABLE SHELVES WITH DIVIDERS
-HORIZONTAL: 60 IN. – ONE (1) REMOVABLE DIVIDER SHELF WITH DIVIDERS
-REAR VERTICAL: 24 IN. X 30 IN. HIGH – OUTRIGGER CUTOUTS
-HOT STICK SHELF:156 IN. LONG WITH WOOD LINED SHELF AND REAR DROPDOWN ACCESS DOOR.
CURBSIDE COMPARTMENTS:
-1ST VERTICAL: 24 IN. – FIVE (5) FIXED MATERIAL HOOKS (1-3-1).
-2ND VERTICAL: 24 IN. – TREAD PLATE ACCESS STEPS TO BED AREA WITH GRAB HANDLE ON EACH SIDE
-3RD VERTICAL: 24 IN. – TWO (2) ADJUSTABLE SHELVES WITH DIVIDERS
-HORIZONTAL: 60 IN. – ONE (1) REMOVABLE DIVIDER SHELF WITH DIVIDERS
-REAR VERTICAL: 24 IN. X 30 IN. HIGH – OUTRIGGER CUTOUTS
-HOT STICK SHELF:108 IN. LONG WITH WOOD LINED SHELF AND REAR DROPDOWN ACCESS DOOR.
-TAIL SHELF: 36 IN. TREAD PLATE TAIL SHELF.
-REAR LIGHTING: 9-LAMP LIGHT BAR INSTALLED AT REAR OF TAIL SHELF AND RUBBER
-MOUNTED RECESSED REAR LIGHTING KIT WITH LED LIGHTS.
-WHEEL CHOCK STORAGE: – ONE (1) EACH SIDE BUILT INTO WHEEL WELLS.

INCLUDES THE FOLLOWING:
-PINTLE HITCH, REINFORCEMENTS, AND D RINGS
-TWO (2) AMBER/GREEN STROBE LIGHTS IN FRONT GRILL AND TWO (2) AMBER GREEN STROBE LIGHTS IN REAR TAILSHELF
-TWO AMBER/GREEN GRILL STROBES, ONE ON EACH SIDE OF BODY CENTERED
-ONE AMBER/GREEN LO-PRO LIGHTBAR, LOCATION TBD
-FOUR LED WORK LIGHT BARS, TWO EACH SIDE OF BODY
-2 REMOTE GO LIGHTS W/LOCATION TBD
-SLOPE INDICATORS, OUTRIGGER PAD HOLDERS, CABLE ACCESS STEPS AND HANDRAILS.
-OUTRIGGER PADS, PAIR OF RUBBER WHEEL CHOCKS AND 3 PIECE TRIANGLE REFLECTOR KIT.
-PD18 (20,000LBS) BRADEN PACCAR WINCH WITH CAPSTAN
-TESTED AND CERTIFIED PER ANSI A92.2



PRICE DOES NOT INCLUDE SALES TAX, PLATE, TITLE!!!!
